Item No :
solis 150KW three phase hybrid inverterOrder(MOQ) :
NegotiablePayment :
T/T, etcProduct Origin :
ChinaColor :
WhiteShipping Port :
Shanghai, Ningbo, ShenzhenLead Time :
5-15 DaysWeight :
170KGProduct Introduction
Inverter Parameters
|
Models
|
100K | 125K | 150K |
|
Recommended max. PV array size
|
200 kW
|
250 kW
|
250 kW
|
|
MPPT voltage range
|
150 - 950 V
|
||
|
Max. short circuit current
|
10 × 65 A
|
||
|
MPPT number / Max. input strings number
|
10 / 20
|
||
|
Battery voltage range
|
300 - 950 V
|
||
|
Max. charge / discharge current
|
100 A × 2
|
||
|
Number of battery ports
|
2
|
||
|
Communication
|
CAN / RS485
|
||
|
Rated grid voltage
|
3/(N)/PE, 480 V
|
||
|
Rated output power
|
100 kW
|
125KW | 150KW |
|
Rated grid frequency
|
60 Hz
|
||
|
Max. efficiency
|
97.6%
|
||
|
BAT charged by PV max. efficiency
|
98.5%
|
||
|
BAT charged / discharged to AC max. efficiency
|
97.0%
|
||
|
Dimensions (W × H × D)
|
50.51 × 33.94 × 18.43 in (1283 × 862 × 468 mm)
|
||
|
Weight
|
374.79 lbs (170 kgs)
|
||
|
Grid connection standard
|
IEEE 1547-2018, Rule 21 (CA), Rule 14 (HI), ISONE
|
||
|
Safety Standard Compliance
|
UL1741SB, IEEE1547-2018, UL1699B, UL1998, FCCPart15ClassB, California Rule21,
HECO Rule 14H, NEC 690.12-2020, CAN/CSA C22.2107.1-1, Hawaiian Electric Co. SRD-V2.0
|
||
Energy storage system operation（Day&Night）
Products&Case
Exhibition
Why Choose Greensun
1.We are a real factory and have strict requirements on the quality of products.
2.We provide OEM services for many leading companies around the world. we also have long-term cooperation with Solis, Deye,Growatt, Must,SMA and other tier-one brands.
3.As a factory, we have better control over product costs.
4.Both production and delivery are very fast.
5. Also, we provide stable and long-term after-sales service.
If you have any Solar needs,
You can write to us below⬇️⬇️⬇️，and contact us directly.
We will tailor a specific energy storage product to meet your specific needs.
Colorful touch LCD, IP65 protection degree AC couple to retrofit existing solar system Max. charging/discharging current of350A 6 time periods for battery charging/discharging Support storing energy from diesel generator Max. 16 pcs parallel for on-grid and off-grid operation; Support multiple batteries parallel
combine the best of grid-tied and off-grid designs allows users to use solar-generated power first, store excess in batteries for later use (e.g., peak demand hours or outages), and feed surplus to the grid for credits
100% unbalanced output, each phase AC couple to retrofifit existing solar system Max. 10 pcs parallel for on-grid and off-grid operation; Support multiple batteries parallel
Flexible charge and discharge settings allows for greater utilization of the energy storage system Eligible for enrollment in most VPP programs which yields additional benefifits for the system owner Split Phase Low Voltage Energy Storage Inverters
Advanced MPPT with up to 99.9% efficiency Up to 22A*2 PV input current With IP65 protection degree Up to 200A charging current Supports Li-ion battery BMS communication
Lithium Battery Auto-restart Function, More Convenient for Lithium Battery Charging Intelligent Power supply Mode, Intelligent Distribution of Solal Panel/Mains/ Battery Power Shares Communication Option: External WIFI, Supervise at Any Time High Precision of output voltage,±5%, Take Care of Your Appliances
Colorful touch LCD, IP65 protection degree AC couple to retrofifit existing solar system Max. 16 pcs parallel for on-grid and off-grid operation; Support multiple batteries parallel
• Supports 100% three-phase unbalanced output • 200% PV input capacity to maximize solar energy utilization • Max. 200% overload capability in off-grid mode • Charging and discharging currents of up to 200A • Switching time < 10ms
