Item No :
S6-EH2P(5-8)K02-SV-YD-LOrder(MOQ) :
NegotiablePayment :
T/T, etcProduct Origin :
ChinaColor :
WhiteShipping Port :
Shanghai, Ningbo, ShenzhenLead Time :
5-15 DaysWeight :
28.8 kgProduct Introduction
Inverter Parameters
|
Models
|
5K
|
6K
|
7.5K
|
8K
|
|
Recommended max. PV array size
|
10 kW
|
12 kW
|
16 kW
|
16 kW
|
|
Max. usable PV input power
|
8 kW
|
9.6 kW
|
12.8 kW
|
12.8 kW
|
|
Max. input voltage
|
500 V
|
|||
|
Rated voltage
|
330 V
|
|||
|
Start-up voltage
|
90 V
|
|||
|
MPPT voltage range
|
90 - 435 V
|
|||
|
Max. input current
|
21 A / 21 A
|
21 A / 42 A
|
42 A / 42 A
|
|
|
Max. short circuit current
|
24 A / 24 A
|
24 A / 48 A
|
48 A / 48 A
|
|
|
MPPT number / Max. input strings number
|
2 / 2
|
2 / 3
|
2 / 4
|
|
|
Battery type
|
Li-ion / Lead-acid
|
|||
|
Battery voltage range
|
40 - 60 V
|
|||
|
Max. charge / discharge current
|
112 A
|
135 A
|
190 A
|
190 A
|
|
Communication
|
RS485 / CAN
|
|||
|
Rated grid voltage
|
L+N+PE/2L+PE, 220 V; L1/L2/N(PE), 120(L-N)/240(L1-L2)VAC
|
|||
|
Rated grid frequency
|
50 Hz / 60 Hz
|
|||
|
Power factor
|
> 0.99 (0.8 leading - 0.8 lagging)
|
|||
|
THDi
|
< 3%
|
|||
|
Dimensions (W × H × D)
|
390 × 620 × 237 mm
|
|||
|
Weight
|
28.8 kg
|
|||
|
Topology
|
Transformerless
|
|||
|
Ingress protection
|
IP66 (TYPE 4X)
|
|||
|
Safety / EMC standard
|
IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2, UL 1741, UL 1699B, FCC
|
|||
|
Communication interface
|
Standard: Wi-Fi+LAN+Bluetooth, CAN-BMS, CAN-Parallel×2, RS485-Meter, RS485, DRM, DI, DO×2, Optional: 2G/3G/4G
|
|||
