Item No :
S6-EH2P(10-18)K03-SV-YD-LOrder(MOQ) :
NegotiablePayment :
T/T, etcProduct Origin :
ChinaColor :
WhiteShipping Port :
Shanghai, Ningbo, ShenzhenLead Time :
5-15 DaysWeight :
65.8 kgProduct Introduction
Inverter Parameters
|
Model
|
10K
|
12K
|
14K
|
16K
|
18K
|
| Maximum recommended input power |
16 kW
|
19.2 kW
|
22.4 kW
|
25.6 kW
|
28.8 kW
|
| Maximum input voltage | 550V | ||||
| Nominal voltage | 380V | ||||
| Start-up voltage | 100V | ||||
| MPPT voltage range | 100-450 V | ||||
| MPPT voltage range at full load |
160-450 V
|
186-450 V
|
|||
| Maximum input current per MPPT | 40A | 42A | |||
| Number of MPPTs / Number of strings per MPPT |
3 / 2
|
||||
| Battery Type | Lithium-ion / Lead-acid | ||||
| Battery Voltage Range | 40–60 V | ||||
| Maximum Charge/Discharge Current |
208 A
|
250 A
|
290 A
|
320A | |
| Communication | CAN / RS485 | ||||
| Rated output power | 10KW | 12KW | 14KW | 16KW | 18KW |
| Maximum apparent output power | 2 times the nominal power, for 10 s | ||||
| Backup response time |
<10 s
|
||||
| Phase power | L1/L2/N(Pe), 120V / 240V (Split phase) | ||||
| Nominal output voltage (L1-L2) |
220 V
|
||||
| Nominal output current |
45.5 A
|
54.5 A
|
63.6 A
|
72.7 A
|
81.8 A
|
| Max. output over current protection, 10 sec |
91 A
|
109 A
|
127.2 A
|
145.4 A
|
163.6 A
|
| Dimensions (length × height × width) | 534 × 930 × 297 mm | ||||
| Weight | 65.8 kg | ||||
| Network connection standard | IEEE 1547-2018, IEEE1547.1-2020, CA Rule 21 | ||||
| Safety standard | UL 1741, UL 1741 SB, CSA C22.2107.1-1, UL 1741 PVRSS, UL 1699B, UL 1998 (US) | ||||
| Communication | RS485, Optional: Cellular, Wi-Fi, LAN | ||||
